Our product line includes best in class IP and Design Services for ASIC and FPGA

   PLL
  • PLL and OSC from 180nm to 3nm
  • LC PLL , Ring Oscillator PLL, Customized PLL
  • Ultra Low Jitter/Power/Area
  • Core voltage or IO voltage
  • Spread Spectrum
​    Multiprotocol PMA and Protocol Specific PHYs
  • From 180nm to 16/12nm, 100Mbps up to 25Gbps
  • MPPMA Supports >30 protocols inc. PCIe Gen 1/2/3/4
  • Targeted PHYs for SGMII, 10G-KR, (e)DP and more
  • ISO 26262 compliant and AEC-Q100 qualified
  • TSMC partenr of the year 2017-2020 for AMS IP
   Other IPs
  • Free running OSC (no external components) <30uW
  • Digital Dual-Loop PLL
  • Bi-directional LVDS >1.25Gbps .....2.5Gpbs in FinFET
  • Bandgap, POR
  • Clocking Library - CML buffers & CML Mux

   Comprehensive Design and Verification IP Solutions

   Design IP
- Broad Protocol Support
  • DDR, Ethernet, Serial Bus, Audio/Video, MIPI, Automotive, Bridge, DMA, Flash and High Speed Interfaces
  • Can be rapidly customized on-demand

​    Verification IP - Design to Silicon

  • Simulation, Emulation, Formal, Post Silicon, Memory Models
  • On-demans services for verification projects
  On-chip protection for ESD/EOS/Latch-Up/EMC

  • TakeCharge® includes on-chip ESD (electrostatic discharge) and EOS (electrical overstress) protection devices for low voltage CMOS from 0.25um down to 7nm. Typical I/O application uses are: high-speed, low-leakage, low-capacitance, low-noise, RF, analog, over- and undervoltage tolerance; often combined with beyond standard robustness requirements.

  • PowerQubic® provides on-chip ESD and EOS protection devices for high voltage CMOS/BCD, typically 0.35um down to 0.18um and 5V to 50V. Typical I/O application uses are: automotive, industrial; mostly requiring high robustness for a combination of harsh ESD, EOS, LU (latch-up) and EMI (electromagnetic interference) specs.

  • PhyStar®  groups Sofics’ robust circuit and interface solutions, including custom analog I/O’s, circuits that handle transient disturbances e.g. to provide antenna clipping or POR (power-on-reset), as well as automotive standard PHYs (e.g. a full LIN PHY with integrated ESD, EOS and EMC robustness).
  Memory subsystem and AI platform IP
  • ORBITTM Memory Controller IP, OMCTM saves on area and power while offering >90% DRAM utilization using a proprietary out-of-order scheduling algorithm. It supports HBM3, GDDR6, LPDDR5/4, and DDR4/3/LPDDR4/3.
  • ORBITTM Network-on-Chip (NoC) Bus Interconnect IP, OICTM enables exceptional bus performance and flexible SoC design via automated end-to-end interconnect generation flow.
  • ORBITTM DDR PHY IP, OPHYTM is a high-speed Memory PHY IP optimized for applications such as AI/ML, HPC, mobile and automotive. It is fabricated using 12nm and 14nm technology, supporting GDDR6, LPDDR5/4 with more advanced nodes in the works.
  • ENLIGHTTM Neural Processor Unit (NPU) IP performs various operations of deep neural networks such as convolution, pooling, and non-linear activation functions for the edge computing environments while achieving an excellent PPA score.
